Rev D CHP Max DC Power Supply 5-9
Figure 5.6
DC Power Supply
Module Identity Tab
Display
Fan 2 current Displays fan 2 current in mA.
Configure Sets major low, minor low, minor high, and major high alarm limits of fan
1 and 2 currents.
Show info Lists the four alarm thresholds and graphical display configuration
information.
Show history Displays a graph of fan 2 current (mA) vs. time.
Save history Saves fan 2 current data points vs. time to an Excel file format.
Module Identity tab
This tab only provides status. Refer to Figure 5.6 on page 5-9 to see the various module parameters.
Alarms tab
This tab lists all major and minor alarms as shown in Figure 5.7 on page 5-10.
Table 5.3 Controls and Functions of the Craft Management Software (cont’d)
Control Function
