1508685 Rev D CHP Max Element Management Modules CHP-CMM, CMM-1, SMM, and SMM-1 6-25
Status and Settings tab
Operational Status Displays a color-coded status of the 10 application module slots, 8 chassis
fans (fan bay), and 2 power supplies (PS1 and PS2). Color coding is as
follows:
■ Dark grey = Device operating properly
■ Red = Device operating with a major alarm
■ Yellow = Device operating with a minor alarm
■ Light grey = Device is not present
+5 VDC Displays the 5V
DC output voltage.
Configure Sets major low, minor low, minor high, and major high alarm limits.
Show info Lists the four alarm thresholds and graphical display configuration
information.
Show history Displays a graph of the output voltage vs. time.
Save history Saves output voltage data points vs. time to an Excel file format.
–5 VDC Displays the –5V
DC output voltage.
Configure Sets major low, minor low, minor high, and major high alarm limits.
Show info Lists the four alarm thresholds and graphical display configuration
information.
Show history Displays a graph of the output voltage vs. time.
Save history Saves output voltage data points vs. time to an Excel file format.
+12 VDC Displays the 12V
DC output voltage.
Configure Sets major low, minor low, minor high, and major high alarm limits.
Show info Lists the four alarm thresholds and graphical display configuration
information.
Show history Displays a graph of the output voltage vs. time.
Save history Saves output voltage data points vs. time to an Excel file format.
+3.3 VDC Displays the 3.3V
DC output voltage.
Configure Sets major low, minor low, minor high, and major high alarm limits.
Show info Lists the four alarm thresholds and graphical display configuration
information.
Show history Displays a graph of the output voltage vs. time.
Save history Saves output voltage data points vs. time to an Excel file format.
Autoconfig
Table 6.3 Controls and Functions of the Craft Management Software (cont’d)
Control Function
