Rev D CHP Max5000 Chassis (Rear Fiber Version) 2-15
2. Gently insert each module into a slot in the front of the chassis. Be careful to align
the plastic guide rail on the top of the module with the metal guides on the top of
the chassis.
3. Carefully slide the application module into the chassis until it is fully seated in the
backplane. The latch on the front panel locks when the module is fully seated.
4. If desired, secure the module to the chassis with a lock washer and nut (6 to 20
in-lbs) over the F-connector.
5. Repeat Steps 2 through 4 to install the remaining modules in the chassis.
6. Install a blank panel (P/N CHP-BLANK) into each empty slot at the front of the chassis
to ensure proper cooling of the application modules within the chassis.
7. Refer to Table 2.7 to configure the corresponding modules.
Note When a module is installed in a powered chassis, the Status alarm LED on the
front panel may light if signal cables have not been connected to the unit.
Note Blank panel(s) are not required if the chassis only contains EDFA modules.
Table 2.7 Module Configuration Reference
Module Section
CMM or SMM (CHP-CMM or CHP-SMM) Configuring CMM, CMM-1, SMM, or SMM-1 on
page 5-12
CHP-SMM-2) SMM-2 Configuration on page 6-11
Single-input Forward Transmitter (CHP-FTX-xx-S) Configuring the CHP Forward Transmitter on
page 7-27
Dual-input Forward Transmitter (CHP-FTX-D[XL]xx-S) Configuring the CHP Forward Transmitter on
page 7-27
1GHz dual-input Forward Transmitter
(CHP-GFX[V]-D-xx-S)
Configuring the CHP Forward Transmitter on
page 7-27
1GHz CORWave Forward Transmitter
(CHP-MXxx-xxxx-xx-S)
Configuring the CHP Forward Transmitter on
page 7-27
1GHz dual-input Forward QAM Transmitter
(CHP-GQTX-10-S-xx)
Configuring the CHP Forward Transmitter on
page 7-27
1550nm Externally Modulated Forward Transmitter
(CHP-XMOD-xxx-xx-x) or (CHP-GMOD-xxx-xx-xx)
Configuring the XMOD/GMOD on page 8-9
Dual-input Return Transmitter (CHP-RTXx-10-S-xx) Configuring the RTX on page 9-10
Erbium Doped Fiber Amplifier (EDFA)
(CHP-EDFA-[CG]-xx-x-x)
Configuring the EDFA on page 11-7
