Aruba Instant On 1930 Series User Manual

LED State Meaning
UID Slow ash
(blue)
Locator LED identifying switch located.
O One of these condition exists:
• User has not activated the Locator LED.
• User has turned o the Locator LED.
• User-congurable timeout period has expired; default time-out period
is 30 minutes.
Mode button
The 1930 PoE switches have one Mode LED per port. The Mode LED shows either the port speed or the PoE
status. In PoE mode, it shows whether the port is congured to provide PoE power. The operation of the
Mode LED is controlled by the Mode select button. Press the Mode button to select the PoE mode.
1 Port LEDs
2 LED Mode pushbutton
3 Reset pushbutton (recessed)
Reset button
The Reset button (pictured in the preceding illustration) is used to restore Factory Default settings, or reset
the switch while it is powered on.
• Resetting the Switch — Press and release the button. This action clears any temporary error conditions
that may have occurred and executes the switch self test.
• Restoring Factory Default Conguration — Press and hold down for over 5 seconds, the switch will
then complete its self test and begin operating with its conguration restored to the factory default
Chapter 2 Overview 15

Aruba Instant On 1930 Series Specifications

General

Model	Aruba Instant On 1930 Series
Switching Capacity	Up to 176 Gbps
Layer	Layer 2+
MAC Address Table Size	16K entries
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Ports	8, 24, or 48 10/100/1000BASE-T ports
Uplink Ports	2 or 4 SFP/SFP+ ports
PoE Options	PoE and non-PoE models available
Management	Cloud-managed with Aruba Instant On mobile app or web portal
Mounting	Rack-mountable
Jumbo Frame Support	9216 bytes
Layer 2 Features	VLANs
Security Features	Access Control Lists (ACLs)
Power Supply	Internal power supply
Humidity	15% to 95% non-condensing
Certifications	CE
