Aruba Instant On 1930 Series User Manual

Acoustics
Noise Emmission
Aruba Instant On 1930 8G 2SFP Switch (JL680A) Power: 0 dB no fan
Aruba Instant On 1930 8G PoE Class 4 2SFP 124W
Switch (
JL681A)
Power: 0 dB no fan
Aruba Instant On 1930 24G 4SFP/SFP+ Switch
(JL682A)
Power: 0 dB no fan
Aruba Instant On 1930 24G PoE Class 4 4SFP/SFP
+ 195W Switch (JL683A)
Pressure: 46.1 dBA Power: 60.5 dB
Aruba Instant On 1930 24G PoE Class 4 4SFP/SFP
+ 370W Switch (JL684A)
Pressure: 32.2 dBA Power: 58.5 dB
Aruba Instant On 1930 48G 4SFP/SFP+ Switch
(JL685A)
Power: 0 dB no fan
Aruba Instant On 1930 48G PoE Class 4 4SFP/SFP
+ 370W Switch (JL686A)
Pressure: 40.6 Power: 63.2 dB
Safety
Complies with:
•
EN60950-1:2006+A11:2009+A1:2010+A12:2011 / IEC60950-1:2005; Am1:2009;
• CSA22.2 No. 60950-1-07 2nd; UL60950-1 2nd
• EN 60825-1:2007 / IEC 60825-1:2007 Class 1
Standards
Laser safety information
Technology Compatible with these
IEEE standar
ds
EN/IEC standard
compliance
SFP Lasers
10-T
100-TX
1000-T
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
1000-SX IEEE 802.3z 1000BASE-SX EN/IEC 60825 Class 1 Laser Product
Laser Klasse 1
1000-LX IEEE 802.3z 1000BASE-LX EN/IEC 60825 Class 1 Laser Product
Laser Klasse 1
Chapter 7 Specications 45

Aruba Instant On 1930 Series Specifications

General

Model	Aruba Instant On 1930 Series
Switching Capacity	Up to 176 Gbps
Layer	Layer 2+
MAC Address Table Size	16K entries
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Ports	8, 24, or 48 10/100/1000BASE-T ports
Uplink Ports	2 or 4 SFP/SFP+ ports
PoE Options	PoE and non-PoE models available
Management	Cloud-managed with Aruba Instant On mobile app or web portal
Mounting	Rack-mountable
Jumbo Frame Support	9216 bytes
Layer 2 Features	VLANs
Security Features	Access Control Lists (ACLs)
Power Supply	Internal power supply
Humidity	15% to 95% non-condensing
Certifications	CE
