Aruba S2500 - DAC Removal

30 |Installation Aruba S2500 Series Mobility Access Switch | Installation Guide
DAC Removal
To remove a DAC:
1. Use standard ESD precautions when removing a DAC.
2. Pull the tab on the top of the DAC and pull the DAC out of the port (see ).
Figure 18 DAC Removal
POWER
MENU
ENTER
STATUS
STACK
Some DACs will have a rubber ring, instead of the white tab shown in Figure 18, for removal.
