22 |Installation Aruba S2500 Series Mobility Access Switch | Installation Guide
Do not disassemble the chassis or any module.
Selecting a Location
The S2500, like other network and computing devices, requires an “electronics friendly” environment.
Reliable power. Verify that your electrical outlet is compatible with the S2500 power supplies.
Cool, non-condensing ventilation
For proper operation, the S2500 requires an environment with an ambient air temperature between 0
and 40 ºC (32 to 104 ºF). Humidity must be kept at non-condensing levels between 5 and 95%.
Where a large number of electrical devices are working in the same area, additional air conditioning or
air circulation equipment may be required.
Ample space
For proper air circulation, leave at least 10 cm (4 inches) clearance for the vents on the left, right, front,
and rear of the chassis.
Leave additional space in front of the chassis to access power cords, network cables, and indicator
LEDs.
Limited electromagnetic interference
For best operation, keep the S2500 and all cords and cables at least 0.7 meters (2 feet) from fluorescent
lighting fixtures, and 2 meters (6 feet) from photocopiers, radio transmitters, electric generators, and
other sources of strong electromagnetic interference.
Rack Mount Installation- Standard
The included two-point rack mounting kit provides the necessary hardware to securely mount an S2500 in
standard 19” Telco rack.
Required Tools and Equipment
The following tools and equipment are required for installation of an Aruba S2500 mobility access switch:
Rack Mount Bracket (2x, not used for tabletop installation)
M4 x 8mm Phillips Flat Head Screws (8x, included with rack mount brackets)
M6 x 15mm Phillips Pan Head Screws (4x, 19-inch (48.26 cm) rack system mount screws).
Suitable Screwdrivers for both screw types.
Installation Steps
To install an Aruba S2500 mobility access switch into a two-point 19-inch (48.26 cm) rack system:
1. Place a rack mount bracket over the mounting holes on one side of the mobility access switch (see
Figure 9).
2. Secure the bracket to the mobility access switch using four M4 x 8mm phillips flat head screws and a
suitable screwdriver.
Each S2500 should have its own mounting equipment. Do not place other networking equipment directly on top a
mounted S2500. Failure to do so can result in damage to the device.
Some racks require screws that differ from those included with the S2500. Confirm that you have the correct
screws before installing your S2500.
