ASCOM d41 Configuration Manual

TD 92641EN
21 June 2012 / Ver. G
Configuration Manual
Ascom d41 DECT Handset
19
1 In PDM or the Device Manager in the IMS3, go to the Numbers tab and select
handset(s).
2In the Number menu, select Import contacts > From file.
3 Select the file to be imported and click "Open".
5.6 Call Services
Call services is a configurable menu in the handset. The purpose of the Call services menu
is to provide a user friendly access to system dependent functionality such as absence
handling and call diversion.
The menu is described in User Manual, Ascom d41 DECT Handset, TD 92582EN.
Besides the default Call services functions, it is possible to define 10 extra system specific
call services by codes. The codes can be programmed with pause (P) and auto
disconnection (H). Both Name and Data must be defined for the option to be displayed.
Possible values: Digits 0-9, #, *, 'P' – pause, H – hook.
The programming of the menu is done with PDM. For instructions on how to work with
PDM, see Installation and Operation Manual, Portable Device Manager (PDM), Windows
Version, TD 92325EN.
Using the PDM and the "Edit template" feature, the parameter can be found at
Systems > Common > Call Services > General Service X
Note: Your supplier may have a template example that will configure the call services
menu for the PBX.
5.7 Call Diversion
It is possible to configure user friendly call diversion menus in the handset using PDM/
IMS3. These menus can then be selected in the handset by selecting Calls > Call services >
Divert calls.
Tip: Beside the default call diversion menus, it is possible to define 10 extra system specific
services codes, see 5.6 Call Services.
1 Select Systems > System X (where X represents A - H).
2 Select PBX Settings > Diversion.
3 Select "Internal", "External", "On No Reply", "On Busy", and/or "All Calls"; enter
the following:
• Prefix - the system specific prefix code to be used (if required by the PBX used)
• Suffix - the system specific code required to activate the diversion (for example
"*21*")
• Cancel - the system specific code required to deactivate the diversion (for
example "#23#").
The user can now enter the diversion number in the handset.
5.8 Absence Handling
It is possible to configure user friendly absence menus in the handset using PDM/IMS3.
These menus can then be selected in the handset by selecting Calls > Call services >
Absence. This menu is used to set the reason why a call cannot be answered, for example

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
