ASCOM d41 Configuration Manual

TD 92641EN
21 June 2012 / Ver. G
Configuration Manual
Ascom d41 DECT Handset
25
The parameter settings affect the “normal” mode, that is, not wired headset, and not the
handsfree/loudspeaking mode.
For configuration of headset audio see, 5.19 Headset Configuration.
Note: Changing these parameters may result in lower sound quality and high sound level.
Evaluate carefully before applying.
5.19 Headset Configuration
A headset is recommended if you frequently use the handset and/or want to have both
hands free. The headset comes in two versions, that is, microphone on boom and
microphone on cable.
5.19.1 Selection of Headset Type
In order to achieve optimal audio quality with the different headset types, it is
recommended to set the corresponding headset type. The default setting is "microphone on
a boom", which means that the audio is optimized for using a headset with microphone on a
boom. The headset type can be changed as follows:
1 Select Connections > Headset.
2In the Headset type drop-down list, select the corresponding headset type to be
used.
If "User headset profile" is selected, continue with chapter 5.19.2 User headset
profile.
5.19.2 User headset profile
If the preconfigured headset profiles does not match the headset or the audio performance
is bad, it is possible to configure a headset profile.
1 Select Connections > Headset > User headset profile.
2In the Name of user headset profile field, enter an appropriate name. The name will
be visible and selectable in the handset menu.
3In the Headset mic adjustment drop-down list, select the microphone gain to be used.
4In the Headset speaker adjustment drop-down list, select the speaker gain to be
used.
Note: Changing these parameters may result in a very high sound level which can cause
hearing damage. In addition, these parameters may result in lower sound quality such as
noise and echo. If the audio problems occur, it is noticeable for the person listening on the
conversation. Evaluate carefully before applying.

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
