ASCOM d41 Configuration Manual

TD 92641EN
21 June 2012 / Ver. G
Configuration Manual
Ascom d41 DECT Handset
22
If configured in the PBX, an incoming call to the DECT handset can either be answered
using the DECT handset or mobile. If the user answer the call using the mobile, the Missed
call window will not be displayed in the DECT handset.
1 Select Settings > Answering.
2In the Show missed calls popup drop-down list, select "No" to hide the Missed call
window.
5.11 Own Line Settings
Use the own line settings when it is desired to use the same phonebook in different
systems and in different countries.
The own line settings enables:
• Calling numbers stored with a "+" sign for the international access code. The same
phonebook can be used in different countries.
• Recognizing incoming internal or external calls as numbers stored on international
format in the phonebook. The same phonebook can be used in different systems.
In order for this feature to work, numbers must be stored in the phonebook in
international format with a "+" sign for the international access code. Also, the Own Line
parameters must be configured via PDM/IMS3.
For instructions on how to work with PDM/IMS3, see Installation and Operation Manual,
Portable Device Manager (PDM), Windows Version, TD 92325EN, or Installation and
Operation Manual, IMS3, TD 92762EN.
5.12 Uploadable Language
It is possible to upload one additional language to the handset. The language file is
generated via an Excel file. The Excel file used to generate language files is delivered from
your supplier.
Note: If another language file is uploaded, the first additional language is overwritten.
Certain special characters are allowed when generating the language file, see information
in the Excel file.
To upload an additional language, the PDM or IMS3 is used, go to the devices tab and
select device(s). In the Device menu, select "Upload language...".
A parameter can be altered to match the uploaded language: The parameter controls:
• The characters available for text input
• The sort order in the phonebook.
This parameter is only used when Language is set. The Parameter can be found in the
"Settings" folder.
Note: It is also possible to upload additional language on several handsets of the same
device type (d41) simultaneously using the Baseline function in the IMS3. See Installation
and Operation Manual, IMS3, TD 92762EN.
See also Installation and Operation Manual, Portable Device Manager (PDM), Windows
Version, TD 92325EN.

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
