ASCOM d41 Configuration Manual

TD 92641EN
21 June 2012 / Ver. G
Configuration Manual
Ascom d41 DECT Handset
26
5.20 Display Management Layout
In the Active area of the display, the first 2 rows can show 12 characters each (default). It
is possible to extend the number of rows/characters to be displayed in idle mode/during a
call up to 3 rows with 16 characters each. When extending the rows/characters, the
System name or Owner ID will be hidden in order to allocate space for system dependent
information.
Note: All settings except the default setting require an IP-DECT system with software
version 5.0.x or higher.
1 Select System X.
2In the Display Management Layout drop-down list, select one of the following:
• 2x12 characters
• 2x16 characters
• 3x16 characters, remove Owner ID
• 3x16 characters, remove system name
5.21 Owner identification in the idle display.
It is possible to add owner identification in standby mode of the handset. In a template or
Number in PDM/IMS3, the parameter is found at:
Settings > Owner ID
Note: It is also possible to configure the Owner ID via the handset menu. See User
Manual, Ascom d41 DECT Handset, TD 92582EN.

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
