Configuration Manual
Ascom d41 DECT Handset
27
6 Administration
6.1 Admin Menu Tree
The handset has a hidden menu for system administrators. The Admin menu contains:
• Software and hardware information, IPEI and IPDI
• DECT link and system information
• Centralized Management status
• Fault logging
• License upgrading menu
• Enhanced system menu with ability to alter protection
• Factory reset option
To activate the Admin Menu, enter the Call time screen and press > * < < * <.
The following figure shows the menu tree for the Admin menu in d41.
Figure 4. Admin Menu in d41.
Other menues are described in User Manual, Ascom d41 DECT Handset, TD 92582EN.
Figure 4.
• Device info —>
• DECT info —>
• Centr. Management —>
• Enter license key >
• Logging —>
• System —>
• Frequency band —>
• Factory Reset —>
• Software —>
• Hardware —>
• IPEI/IPDI —>
• User ID —>
• Link —>
• System
• Back
• No. of events —>
• Restart reason —>
• Change system —>
• Subscribe —>
• Unsubscribe —>
• Rename system —>
• Priority —>
• Protection —>
• Select
• Back
• Yes
• No
• Automatically
• System A
• Next —>
• Back
• Select
• Back
• System A —>
• System A —>
• System A —>
• Next
• Clear
• Back
• Back
• Select
• Back
• Change
• Back
• Edit —>
• Back
• Save
• Clear
• Back
• Edit —>
• Back
• Save
• Clear
• Back
• Back

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
