ASCOM d41 Configuration Manual

TD 92641EN
21 June 2012 / Ver. G
Configuration Manual
Ascom d41 DECT Handset
1
1 Introduction
This document is a guide for installing, configuring and maintaining functionality of the
d41 handsets.
The d41 can be used straight away in your system but it is highly recommended to install
the Portable Device Manager (PDM) Windows Version or the Integrated Wireless
Messaging and Services application (IMS3). This enables customization of the behaviour of
the handset to suite each user profile and the specific PBX used in the system.
The PDM Windows Version is aimed for smaller sites where the handsets are within reach.
The IMS3 makes it possible to administrate the handsets centrally via a web interface
without the need to collect the handsets.
It is recommended that the reader has basic knowledge of the Ascom system and basic
knowledge of subscribing handsets to the PBX.
1.1 Abbreviations and Glossary
DECT Digital Enhanced Cordless Telecommunications:
global standard for cordless telephony.
IMS3 Integrated Wireless Messaging and Services
An application running on an ELISE3 module, that enables wireless
services to and from portable devices and chargers.
IPDI International Portable DAM Identity
DAM (DECT Authentication Module)
See IPEI for more information.
IPEI International Portable Equipment Identity:
IPEI/IPDI is needed to enable network subscription of the handset. At
delivery of the handset, IPEI and IPDI are the same and either can be
used for network subscription. If one handset is replaced with
another using the Easy replacement procedure the IPDI will be
exchanged and IPEI and IPDI will no longer be the same. If the IPEI
and the IPDI differ, the IPDI shall be used for network subscription.
OTA Over The Air
PBX Private Branch Exchange:
Telephone system within an enterprise that switches calls between
local lines and allows all users to share a certain number of external
lines.
PDM Portable Device Manager
An application, running on a PC, for management of portable
devices, charging racks, etc.
Unite Generic term for messaging system that unites different systems, for
example System 900, System 9d, and teleCARE M.
User ID User ID identifies the set of user parameters possible to save and
administrate via PDM. It can be moved together with user parameters
between handsets. It is normally set automatically at DECT
subscription to be equal to call number.

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
