ASCOM d41 Configuration Manual

TD 92641EN
21 June 2012 / Ver. G
Configuration Manual
Ascom d41 DECT Handset
3
2 Getting started with Configuration of the d41 Handset
It is possible to configure the d41 Handset by inserting it into a desktop charger (DC4) or
rack charger (CR3). The charger is connected via USB or ethernet to the PDM Windows
Version or the IMS3.
In the case of IP-DECT, it is possible to configure the d41 over the air.
This chapter describes how to configure handsets in three different system setups:
• with PDM Windows Version
• with IMS3 via chargers
• with IMS3 over-the air
2.1 PDM Windows Version
The Windows Version is run on a PC. The handset is configured via PDM Windows Version
as follows:
• Connect a desktop charger (DC4) or a rack charger (CR3) via USB to the computer
running PDM.
•Start PDM.
• Place the handset in this charger which shall be connected to PDM. The handset can
either be turned off or turned on when placing it in the charger. A handset that is
turned off will start up automatically and the battery charging symbol will be displayed.
For instructions on how to use PDM Windows Version, see Installation and Operation
Manual, Portable Device Manager (PDM), Windows Version, TD 92325EN.
Figure 1. Configuration of handsets via PDM Windows Version
2.2 Device Management in IMS3
The Device Manager in IMS3 is running on an ELISE3 module.
For instructions on how to use the IMS3, see Installation and Operation Manual, IMS3,
TD 92762EN.
Figure 1.
PDM

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
