ASCOM d41 Configuration Manual

TD 92641EN
21 June 2012 / Ver. G
Configuration Manual
Ascom d41 DECT Handset
4
2.2.1 Via Chargers
• Connect a desktop charger (DC4) or a rack charger (CR3) via the Ethernet port to the
network.
The charger is by default configured to connect to the network using DHCP. If DHCP is
not used in the network, connect each charger via USB to a PDM Windows Version
and configure a static IP address.
• Start the IMS3.
• Place the handset in a charger that is connected to the IMS3. The handset can either
be turned off or turned on when placing it in the charger. A handset that is turned off
will start up automatically and the battery charging symbol will be displayed.
Figure 2. Configuration of handsets via IMS3 and chargers.
2.2.2 Over-the-air via IP-DECT
There is no external equipment needed besides IMS3 and IP-DECT. Please proceed with
3 Installation of Handsets on page 5.
Figure 3. Configuration of handsets via IMS3 and over-the-air.
Figure 2.
Figure 3.
Client
IMS3
IP
Client
IPBS
Ascom
IP-DECT
System
IMS3

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
