Ascon tecnologic X5 Series User Manual

17
3 - Electrical Connections
3.3.6-A SINGLE ACTION RELAY
(TRIAC) CONTROL OUTPUT
B
3.3.6-B1 SINGLE ACTION SSR DRIVE
CONTROL OUTPUT
B
3.3.6-B2 SINGLE ACTION
ANALOGUE OUTPUT
B
3.3.6-C DOUBLE ACTION
RELAY (TRIAC)/RELAY (TRIAC) CONTROL OUTPUT
B
3.3.6-D1 DOUBLE ACTION
RELAY (TRIAC)/SSR DRIVE CONTROL OUTPUT
B
3.3.6-D2 DOUBLE ACTION CONTROL OUTPUT
RELAY (TRIAC)/ANALOGUE CONTROL OUTPUT
B
Fuse
Coil of the heat
load contactor
31
32
OP1
[1]
Fuse
Coil of the heat
load contactor
31
32
OP1
[1]
Fuse
Coil of the cool
load contactor
32
33
OP2
[1]
Fuse
Coil of the heat
load contactor
31
32
OP1
[1]
Heat
load
Static
Relay
8
9
OP5
Cool
load
Static
Relay
8
9
OP5
8
9
OP5
Heat
load
mA
mV, V
Fuse
Coil of the heat
load contactor
31
32
OP1
[1]
8
9
OP5
Cool
load
mA mV,V
