4 - Operation

4.4.4 PARAMETERISATION TUNING MENU

(not shown for ON-OFF control action)

4.4.5 PARAMETERISATION

INPUT MENU

Tune

t.d.

t.i.

p.b.

AdPt

éno

tune

éno

InP

T.SaM

é 0:11

In.Sh

é 0

t.FiL

éOFF

Initial

tune start

(One shot tune)

no/yes

Continuous

Tune start

Adaptive Tune (A.T.)

no/yes

Calculated Proportional

band [1] (display only)

(available when adaptive

tune is selected)

Calculated Integral

time [1] (display only)

(available when adaptive

tune is selected)

Calculated derivative

time [1] (display only)

(available when adaptive

tune is selected)

Filter time constant

(user enabled/disabled)

Off/0.2…99.9 seconds

Measure bias

-60…60 digit

Sampling time

0.1…10.0 seconds

Tuning

Input

#No

#yeS

for AT

[1] These values

are not automati-

cally stored on the

PID menu parame-

ters

P.b., t.i., t.d.
