1 - Introduction
1 INTRODUCTION
Main universal input
Control Alarms Retransmission
Resources
PV
AUX
IL1
IL2
IL3
OP1
OP2
OP3
OP4
OP5
OP6
(option)
X5
Setpoint
Continuous tuning
Adaptive
Operating mode
Memory Chip
Data copy/Data store
(option)
Auxiliary input
Digital input
PV/SP/OP
Digital inputs (IL1,IL2 or IL3) functions
Fuzzy tuning with automatic selection
One shot
Auto tuning
One shot
Natural Frequency
(option)
(option)
POWERFUL FEATURES
AND A WIDE RANGE
OF FUNCTIONALITIES
Congratulations for having
chosen these universal
controllers. They are the best
result of our experience in
designing and manufacturing
of smart, powerful and high
reliable controllers.
The process controllers of the
X5 series have been designed
for the industrial environment,
are provided with a complete
set of functions, as a true
universal instrument.
They can be used as
Controllers-Programmers with
4 Setpoint profiles of 16
segments.
Modbus RS485 Master
link to other instruments
(option)
Modbus RS485 Slave
Parameterization Supervision
(option)
