Ascon tecnologic X5 Series User Manual

P/N
CONF
S/N
V
~(L-N)
: X5-3150-0000
:
: A0A-9919/0013
: 100÷240V 50/60 Hz - 5W
I 1 I 2 I 3
45.80
45.80
X5
50
B C D
5
1 - Introduction
1.1 MODEL CODE
The complete code is displayed
on the instrument label.
The information about product
coding are accessible from the
front panel by mean of a partic-
ular procedure described at sec-
tion 5.1 page 53.
Note:
[1] Not available with split range
control mode
Basic product code
Instrument label
Model:
Power Supply
Outputs
Serial + mathematical package (MP)
Options
––
Line Basic model Accessories
Colour
User manual
Setpoint
0X5 A B C D E F G
Power supply A
100...240Vac (- 15% + 10%)
3
24Vac (-25...+12%) or
24Vdc (-15... +25%)
5
Triac - Triac
5
Outputs OP1 - OP2 B
Relay - Relay
1
RS485 Modbus/Jbus
SLAVE + MP
5
Serial Communications C
None
0
2
nd
SSR drive/analogue
output (OP6)
4
Options D
None
0
RS485 Modbus/Jbus
SLAVE + MASTER + MP
6
PROFIBUS DP SLAVE
+ MP
7
RS485 Modbus/Jbus
SLAVE + PROFIBUS + MP
8
Setpoint Programmer [1] E
Not fitted
0
4 programs with 16 segments
4
User manual F
Italian/English (std.)
0
French/English
1
German/English
2
Spanish/English
3
Front panel colour G
Dark (std.)
0
Beige
1
Frequency input
1
Frequency input + OP6
6
Mathematical package (MP)
1
x5-uk-ed5 17-09-2009 14:53 Pagina 5
