3 - Electrical Connections
3.3.6-G MOTOR POSITIONER OUTPUT
RELAY (TRIAC)/RELAY (TRIAC)
Valve drive PID without potentiometer
3 pole output with N.O. contacts
(increase, decrease, stop)
OP1
33
32
31
OP2
Vac
Decrease
Increase
M
~
3.3.6-F4 DOUBLE ACTION CONTROL OUTPUT OR SPLIT RANGE
ANALOGUE / ANALOGUE
B
20
21
OP6
Cool
load
mA
V, mV
3.3.6-F2 DOUBLE ACTION CONTROL OUTPUT
DIGITAL / ANALOGUE
B
3.3.6-F3 DOUBLE ACTION CONTROL OUTPUT
ANALOGUE / DIGITAL
B
8
9
OP5
Heat
load
mA
mV, V
8
9
OP5
Heat
load
mA
mV, V
Cool
load
Static
Relay
20
21
OP6
20
21
OP6
Cool
load
mA
V, mV
Heat
load
Static
Relay
8
9
OP5
