Ascon tecnologic X5 Series User Manual

72
8 - Technical Specifications
Features
at 25°C env. temp.
Description
OP1-OP2 outputs
SPST Relay N.O., 2A/250Vac (4A/120Vac) for resistive load
Triac, 1A/250Vac for resistive load
Galvanic isolation
: 500 Vac/1 min
Short circuit protected
Resolution: 12 bit
Accuracy
: 0.1 %
OP3 output SPDT relay N.O., 2A/250Vac (4A/120Vac) for resistive load
Active low
OP4 output SPST relay N.O. 2A/250Vac (4A/120Vac) for resistive load
Analogue/digital
OP5 and
OP6 (option) outputs
Control or PV/SP/OP
retransmission
Analogue: 0/1... 5V, 0…10V, 500Ω/20mA max.,
0/4... 20mA, 750Ω/15V max.
Digital:
0/24Vdc ±10%; 30mA max.
for solid state relay
AL1 - AL2 - AL3 - AL4
alarms
Hysteresis 0…5% Span in engineering units
Action
Active high
Action type
Deviation threshold ±range
Band threshold 0… range
Absolute threshold whole range
Special functions
Sensor break, heater break alarm
Acknowledge (latching), activation inhibit (blocking)
Connected to Timer or program (if options installed) (only OP3-OP4)
Setpoint
Local + 3 memorised
Up and down ramps 0.1...999.9 digit/min or digit/hour (OFF=0)
Low limit: from low range to high limit
High limit: from low limit to high range
Remote only
Local and Remote
Local with trim
Remote with trim
Programmable If option installed
