Ascon tecnologic X5 Series User Manual

7
2 - Installation
2.1.1 DIMENSIONAL DETAILS 2.1.2 PANEL CUT-OUT
96 mm
3.78 in
110 mm
4.33 in
48 mm
1.89 in
10 mm max.
0.39 in max.
10 mm max.
0.39 in max.
65 mm min
2.56 in min
45
+0.6
mm
1.78
+0.023
in
92
+0.8
mm
3.62
+0.031
in
113 mm min
4.45 in min
x5-uk-ed5 17-09-2009 14:53 Pagina 7
