AC24/30/36 Operations Manual....
14
5.1 MECHANICAL INSTALLATION
The systems were designed for deck-mount installations and as such are provided with six mounting
holes, three per side. Mounting holes have been provided with ½" (12mm) diameters, stainless steel
hardware in the range of 3/8" to 7/16" (10-11mm) diameter is required.
The mounting surface should be flat and dimensionally stable to within 1/16" (1.5mm) to prevent
torsional stresses being applied to the structure of the converter. Spacers (shim stock) may be added
between the mounting surface and the converter mounting flanges to adjust the mounting plane. If
the system is to be mounted in a high vibration/shock environment, then the factory must be
consulted concerning the application. Drawings for approved shock mounting panels will be
supplied.
The following recommended clearances must be considered during installation for proper operation:
TABLE 1
FOR PROPER:
Operation Service
Front 18" (Airflow) 24" min
Lower Rear Sides 6" (Airflow) 0"
Top (Excluding Keypad) 0" 14"
Rear 3" (Airflow) 0"
