AGC CONTROL SCREEN
Automatic Gain Control is: ENABLED
Enable Disable Exit
7.6 AGC CONTROL
Press the SHORE POWER + F4 buttons to access the Automatic Gain Control (AGC) CONTROL
display.
This function enables or disables AGC. Press the Enable (F1) button to enable the feature, the
Disable (F2) button to disable the feature, and the Exit (F5) button to save the settings and exit.
Default Range
Automatic Gain Control Enabled Enabled, Disabled
Application: this function will compensate for changes in output voltage not already corrected by
hardware and software calibration such as load-dependent output voltage variances. This function
should be disabled before calibrating the hardware oscillator and current compensation pots on the
Modulator Interface PCB (usually only done when initially setting the output voltage configuration
at the factory). It must be disabled when using Converter Output Impedance Control (see page 43).
