5.2.2 Output Power Connections
Each converter is supplied with compression type terminal blocks for output power connections.
These terminal blocks accept wires in the range of 2/0 to 8AWG. Refer to the applicable standard
for selection of the required wire gauge and type. Please refer to the FIGURE 3 on the previous
page for additional detail.
Prepare the power cable by removing the outer cable insulation approximately 6". Strip the
insulation back exposing ½" of bare conductor on all three conductors. Insert the prepared cable and
strain relief assembly into the forward hole in the input service panel. Insert the wire ends into the
output terminal block as described below and tighten.
THE CONVERTER ISOLATES THE OUTPUT POWER FROM THE INPUT
POWER AND EQUIPMENT (SAFETY) GROUNDS SIMILAR TO AN
ISOLATION TRANSFORMER. THE INSTALLER MUST RE-ESTABLISH
THE GROUND REFERENCE FOR THE EQUIPMENT AT TIME OF
INSTALLATION. NEUTRAL AND EQUIPMENT (SAFETY) GROUNDS TO
BE CONNECTED PER ABYC STANDARDS.
For 120/240V or 110/220V two-phase systems, connect the ship’s electrical system to the converter
output terminals: L1, N (Neutral), and L2. Connect N (Neutral) to chassis ground at the converter
panel or at the distribution panel. L1 and L2 will measure 120V or 110V in reference to N.
