AC24/30/36 Operations Manual....
25
6.1 POWER TURN-ON PROCEDURE, cont.
Press the SHORE POWER (2) display button. The display will indicate basic shore power
information; voltage, frequency, kVA, and current. Verify the displayed voltage(s) indicate the
expected voltage(s) and frequency Additional SHORE POWER information can be obtained by
pressing the F2, F3, and F4 (13) buttons. Return to the primary screen by pressing the F1 (13)
button.
To start the system, press the SHORE POWER ON (7) button. The system will begin a soft-start
procedure which requires approximately 2 seconds to complete. At the conclusion of this process,
the indicator LED (7A & 10A) in the SHORE POWER control area of the display should change
from red to green. View the display information for CONVERTER POWER (4), verify the
displayed voltage is at the desired potential, frequency, and form. If not, do not proceed until
contacting factory personnel.
NOTE: It is normal under no load conditions for the currents to indicate 2-4 Amps flowing. This
level of current is due to the internal filters and will not degrade the systems power rating.
6.1.1 Systems Not Equipped With The Seamless Transfer Option
When ready to transfer the yacht’s load to the converter, press the CONVERTER POWER ON (8)
button. This will place voltage at the output terminals of the converter. The green ON indicator
LED (8A) should now be lit. The ship’s load may be transferred to the converter at this time.
When load has been transferred to the converter, monitor the load currents and voltages. Ensure the
load is within the converter’s ratings. Monitor the shore power voltage and current levels with load
applied. Refer to published rating curves for maximum current, kVA, and kW levels.
