7.10 DIAGNOSTICS
As previously described in paragraph 6.1, the converter’s LCD display will initiate on turn-on in the
SUMMARY DISPLAY (as shown below) indicating the converter’s operational state.
Return to this screen at any time by pressing the SYSTEM STATUS (5) button. Press the F4 (13)
button to view the converter’s INFO screen that details the reason why the SHORE POWER is OFF
when it had previously been ON. Otherwise, it will simply state INPUT is ONLINE. In the event of
a converter failure or over-temperature condition, “WARNING” or “FAILURE” may flash in the
lower-right-hand corner of this display. If this occurs, press the F5 (13) button to bring up a plain-
language display which details the cause of the warning or failure condition. By pressing the F1 and
F2 (13) buttons simultaneously, the warning or failure condition will clear if the event causing the
warning or failure has ended and “WARNING” or “FAILURE” will discontinue flashing. Pressing
the F5 (13) button will now bring up the SYSTEM IDENTIFICATION DISPLAY where the
software version can be read from.
SUMMARY DISPLAY AC24 MASTER
INPUT#1:OFFLINE CONVERTER: ONLINE
LOAD LEVEL: XX.X% AUTO-RESTART: ON
INFO STATUS
ASEA MARINE CONVERTER SYSTEM STATUS: OK
AC MARINE POWER CONVERTER Version X.XX
©200X ASEA POWER SYSTEMS
HOURS OF OPERATION XX:XX:XX
To Next Page
