AC24/30/36 Operations Manual....
50
7.10 DIAGNOSTICS, cont.
To aid in system diagnostics, three status words have been provided in the STATUS WORD
DISPLAY which is accessed by pressing the SYSTEM STATUS (5) and F2 (13) buttons
simultaneously. Additionally, a configuration word is provided in HEX format.
Each word is comprised of 16 digits, each indicating a separate internal logic term. On the right
hand side of the STATUS WORD DISPLAY, the same information is given in HEX format. If
reporting problems to the factory, please use the HEX format (example... STATUS 1: DF85) to
reduce the chance of transcription error.
If a problem has been encountered by the system, carefully record the status words before removing
power to the system. When calling the factory for assistance, please have the CONFIG word in hex,
status words in hex, model number, serial number, and software version.
BIT: FEDCBA9876543210 CON: XXXX XXXX
SW1: XXXXXXXXXXXXXXXX STATUS1: XXXX
SW2: XXXXXXXXXXXXXXXX STATUS2: XXXX
SW3: XXXXXXXXXXXXXXXX STATUS3: XXXX
