AC24/30/36 Operations Manual....
18
5.2 ELECTRICAL INSTALLATION
This procedure assumes the physical installation of the converter has been completed. It is the users
responsibility to provide input service over-current protection and disconnect means. Follow the
table below for shore power wiring.
Model AC24 AC30 AC36
Input Current, Single Shore Cord 100A 125A 150A
Dual Shore Cord 50A 63A 75A
Output Current 100A 125A 150A
All power wiring requires the removal of the front panel, the interior safety cover, and the power
cable access cover (cabinet bottom). This cover is secured with 6 ea 1/4-20" x ½" stainless steel
screws. Drill or punch the appropriate holes for the selected strain reliefs. Re-install the input
service panel using the removed hardware. Place the disconnect switch in the OFF position.
INPUT WIRING MUST BE PERFORMED BY A QUALIFIED ELECTRICIAN
FAMILIAR WITH STANDARD SAFEGUARDS AND PROCEDURES REQUIRED
BY THE INSTALLATION OF THIS TYPE OF EQUIPMENT. POWER MUST BE
REMOVED FROM THE INPUT DISTRIBUTION SYSTEMS SUPPLYING
POWER TO THE AC24 PRIOR TO THE START OF THE FOLLOWING STEPS.
INPUT POWER MUST BE SECURED (LOCKED) IN THE OFF (DE-ENERGIZED)
STATE UNTIL INSTRUCTED OTHERWISE BY THIS DOCUMENT.
FAILURE TO FOLLOW THESE PROCEDURE CAN RESULT IN DAMAGE TO
THE EQUIPMENT, AND CAN PRESENT THE RISK OF INJURY OR DEATH TO
THE INSTALLER OR THE OPERATOR.
