ASEA AC24 - Control, Metering, and Status; Physical Specifications; Mechanical; Environmental

AC24/30/36 Operations Manual....
11
4.1 ELECTRICAL SPECIFICATIONS, cont.
4.1.3 Control, Metering, and Status
Shore Power Control Input Service Disconnect Switch, 2 pos.
Membrane Switch, Input ON/OFF Control
Ship’s Power Control Membrane Switch, Output ON/OFF Control
Membrane Switch, Generator/Converter Transfer Control
Shore Power Metering Voltage, Current, kVA, kW, PF, Frequency, %Load, kVAR
Generator Power Metering Voltage and Frequency
Converter Power Metering Voltage, Current, kVA, kW, PF, Frequency, %Load, kVAR
System Status Operational status, Diagnostics, Software Calibration
4.2 PHYSICAL SPECIFICATIONS
Parameter AC24 AC30 AC36
4.2.1 Mechanical
Height 40.94"/104cm 40.94"/104cm 40.94"/104cm
Width, Enclosure 18"/45.7cm 18"/45.7cm 18"/45.7cm
Depth 30.25"/76.8cm 30.25"/76.8cm 30.25"/76.8cm
Weight 606lbs/275kg 628bs/285kg 628lbs/285kg
4.2.2 Environmental
Ambient Temperature Range 0-50C non-condensing
Air Exchange Rate 600CFM
