2 phases - 1 neutral3 phases - 1 neutral
4x1.5 mm
2
Cross sectional area:
Cross sectional area:
5x1.5 mm
2
2 phases - 2 neutral (only for NL)1 phase - 1 neutral
5x1.5 mm
2
Cross sectional area:
Cross sectional area:
3x4 mm
2
Connection diagram
NOTE!
Consult the wiring diagrams on the front of the appliance.
• Open the cover of the connection terminal box.
• Run the power cord through a cord strain relief (clamp) which
protects the cable from being pulled out.
• Connect the wires according to your type of appliance.
• The jumpers are provided on the connection terminal.
