The oven must be centred in the unit so
that there is a minimum distance of 5 mm
between it and the surrounding unit.
•
The housing unit or its outer surface
must be capable of withstanding heat.
•
To ensure the oven rests firmly in the
housing, screw it to the housing unit
using the holes on the side uprights
provided (see diagram).
To do this:
1
Remove the rubber stoppers masking the
fixing holes.
2
To prevent the housing unit splintering, drill
two holes 3 mm in diameter in the wall of
the housing unit opposite the fixing holes.
3
Attach the oven using the two screws.
Conceal the hole using the rubber stoppers.
(These also help to cushion the closing of
the oven door).
(*) If the housing unit is open at the back,
the gap must not be more than 70mm.
