42
EN
Installation
Inserting batteries
The battery must be inserted prior to the installation of the electronic knob
cylinder C100V3. The battery compartment is located in the respective electronic
part of the electronic knob cylinder C100V3.
1 Insert the battery (type CR2) as shown in Pic.12, page80.
Installing the double cylinder
1 Familiarise yourself with the components and the accompanying tool.
2 Install the electronic knob cylinder C100V3 as shown in Pic.5, page74 to
Pic.6, page75.
The electronic knob cylinder C100V3 is completely installed and can now be
tested for compete functionality.
Installing the half-cylinder
1 Familiarise yourself with the components and the accompanying tool.
2 Install the electronic knob cylinder C100V3 (half-cylinder) as shown
in Pic.7, page76 to Pic.11, page79 and following.
The electronic knob cylinder C100V3 is completely installed and can now be
tested for compete functionality.
Testing the installed knob cylinder
1 Test all functions of the installed knob cylinder. In the process, observe the
following:
1.1 Make sure that locks or seals mounted on the complete door unit do not
impede the proper operation.
1.2 Protruding parts of the knob cylinder may not impede the free swinging
of the door.
The knob cylinder is completely installed and tested for compete
functionality.
Hub connection
Online connection via a hub is standard. The C900 version of the knob cylinder
can be operated offline.
1 Install the hub as shown in Pic.13, page81.
2 Connect the hub according to the layout plan.
The knob cylinder can be controlled online.
Approved 2017-08-16
