44
EN
Technical specifications
RFID reader technical specifications
Characteristic Characteristic
RFID technology iCLASS
®
MIFARE™ classic
MIFARE™ DESFire™
MIFARE™ PLUS
RFID reader UID / sector block / application file
Read distance (typical) < 4 cm
Radio standard IEEE 802.15.4 (2.4 GHz)
Encryption (radio) AES 128 bit
Maximum distance to the hub
(depends on the hub type and struc-
tural conditions)
5 m
(25 m)
Battery 1 x lithium CR2 3 V with min. 800 mAh
Battery service life at 20 °C 30,000 cycles in max. 2 years
Approved 2017-08-16
