Assa Abloy Yale 5300LN Series User Manual

September 2003
Page 11
5300LN Series Parts & Service Manual
5328LN
22
4
5.1
6.
1
3
2
1.1
1.
2
Sold as complete lockbody
assembly only.
Passage Lock
Lever x Blank Plate
1.1 Flange (Standard Door) 1 -
1.2 Flange (Thick Door) - 1
2Spindle - Inside 1 1
3Frame 11
4 Spring - Retractor 2 2
5.1 Locator, Retractor Spring 1 1
6.1 Retractor #1 1 1
22 Flange Assembly, Outside 1 1
ITEM DESCRIPTION DOOR DOOR
Assembly #
*14-5328-0001-048
1-3/8" to 1-3/4"
Assembly #
*14-5328-0002-048
2" to 2-1/4"
QU
ANTITY
