5300LN Series Parts & Service Manual
1.2
1.1
8
9
10.1
19
20
7
18
4
5.1
6.1
21
3
2
1.1
1.2
Sold as complete lockbody
assembly only.
Classroom Lock F84
1.1 Flange (Standard Door) 2 -
1.2 Flange (For 2” to 2-1/4” Door) - 2
2Spindle - Inside 1 1
3Frame 11
4 Spring - Retractor 2 2
5.1 Locator, Retractor Spring 1 1
6.1 Retractor #1 1 1
7 Spindle, Outside 1 1
8Seat, Spring 1 1
9 Spring, Pawl 1 1
10.1 Pawl 1 1
18 Release Tube 1 1
19 Stop Pin 1 1
20 Cam Tube Driver 1 1
21 Cam Tube 1 1
ITEM DESCRIPTION DOOR DOOR
Assembly #
*14-5308-0064-048
1-3/8" to 1-3/4"
Assembly #
*14-5308-0065-048
2" to 2-1/4"
QU
ANTITY
August 2003
