Assa Abloy Yale 5300LN Series - 5305 LN Storeroom Lockset F86

September 2003
5305LN
Page 6
5300LN Series Parts & Service Manual
1.2
1.1
or
8
9
10.1
4
3
1.21.1
or
7
24
5.2
6.2
2
11.2
Sold as complete lockbody
assembly only.
Storeroom Lockset F86
1.1 Flange (Standard Door) 2 -
1.2 Flange (Thick Door) - 2
2Spindle - Inside 1 1
3Frame 11
4 Spring - Retractor 2 2
5.2 Catch 1 1
6.2 Retractor #2 1 1
7 Spindle, Outside 1 1
8Seat, Spring 1 1
9 Spring, Pawl 1 1
10.1 Pawl, Modified 1 1
11.2 Tube, Release 1 1
ITEM DESCRIPTION DOOR DOOR
Assembly #
*14-5305-0079-048
1-3/8" to 1-3/4"
Assembly #
*14-5305-0080-048
2" to 2-1/4"
QU
ANTITY
