Start up LDM41A and LDM42A Manual
Page 22 ASTECH GmbH
7 Start up
Make sure that all cable ends are protected against short circuit effects before
you turn on power supply!
Connect cable terminals as required for the particular operating mode. To
prevent short circuits, you should seal unused cable ends!
For starting up, a PC with RS232 or RS232 data interface and a terminal
program are required. We recommend the Windows program LDMTOOL
Version 3.0 or higher.
Figure 10 : Program LDMTool
As part of preparative actions, the LDM41A and LDM42A must be properly
installed in the designated working site, oriented onto the target and kept in a
stable position. The target to be measured should preferentially have a
homogeneous, bright surface.
