Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
116
Level 1
Level 2
Level 3
Setting item
Setting value
HTPDN Ctrl 1, 2, 3, 4
LOCHN Ctrl 1, 2, 3, 4
Controls channel 1, channel 2, channel 3, and channel 4.
0: Through
1: Low
2: Hight
・ When the dot clock operation mode (DotClk Mode) is Auto, the number of data lanes is switched automatically according to the
dot clock.
For details, refer to the DotClk Mode settings of “2.1ALL OUTPUT”.
