Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
68
4.2.5 DisplayPort output setting items
This section describes output settings for the DisplayPort unit.
Level 1
Level 2
Level 3
Setting item
Setting value
DisplayPort
Output
OFF/ON
[VG-876, 879]
Port1 to Port8
Sets ON/OFF for each Port.
0: OFF / 1: ON
Video Output
Sets video output to on or off.
0: OFF / 1: ON
Audio Output
Sets embedded audio output.
0: OFF / 1: ON
Trans Mode
Sets the video stream transmission mode.
* The setting is enabled only for VM-1876A-M1.
When selecting MST, set the Configuration → DP → Select Function setting to MST.
For details, refer to “4.2.6 DisplayPort configuration setting items”.
0: SST / 1: MST
When Trans Mode = 0 (SST) is selected, the following setting items are displayed.
DotClk Range
* This is in accordance with the DotClk Mode setting in “2.1 ALL OUTPUT”.
0:Under 340MHz
1:Under680MHz
2:Over680MHz
Output Mode
Sets the screen split output
mode.
* This is in accordance with
the Split Mode setting in
“2.1 ALL OUTPUT”.
* The items differ
depending on DotClk
Range.
When DotClk Range = Under 680 MHz
0: Top / Bottom
1: Left / Right
2: Top / Bottom
3: Left / Right
4: No Split
5: Even / Odd
6: No Split
7: Even / Odd
8: Left / Right
9: Left / Right
When DotClk Range = Over 680 MHz
0: Top Bottom
1: Reserve
2: Top Bottom
3: Reserve
4: Left / Right
5: Left / Right
6: Left / Right
7: Reserve
8: Reserve
9: Even / Odd
When Trans Mode = 1 (MST) is selected, the following setting items are displayed.
Stream Count
Sets the number of streams to transmit.
* This is in accordance with the DotClk Mode setting in “2.1 ALL OUTPUT”.
0: No Output
1: 2 Stream
2: No Output
Output Mode
Sets the stream output mode.
* This is in accordance with the Split Mode setting in “2.1 ALL OUTPUT”.
When 2 streams
0: Top / Bottom
1: Left / Right
2: Top / Bottom
3: Left / Right
4: Even / Odd
5: Even / Odd
6: Even / Odd
7: Even / Odd
8: Left / Right
9: Left / Right
