Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
60
4.2.2 DisplayPort Unit VM-1876A-M1
● Unit exterior diagram
No.
Name
Description
①
DisplayPort outputs
The same video can be output from two lines at the same time
Also, output with rendering split between the CH1 and CH2 set is possible.
Multiple streams (maximum of 2 streams) can be transmitted from one connector by
using Multi Stream Transport (MST) mode.
②
Standby LED
Lights when output preparation is complete.
On: Normal
Off: Error (module damaged, wrong slot, etc.)
・ HDCP settings
VM-1876A-M1 does not support HDCP.
①
②
