Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
152
4.6.7 Synchronization unit setting items
《VM-1876-MX Setting Parameters》
0: OFF
Does not operate in the synchronization mode.
1: Master
Operates in the synchronization mode as the master device.
2: Slave
Operates in the synchronization mode as a slave device.
Position
Sets the rendering position of the
VG.
* This is dependent on the Multi
VGMode setting of All Output.
* Please do not set this to Position 3
and Position 4 when Multi VGMode =
2VDiv.
For details on output, refer to “4.6.4
Image of splitting method when
synchronizing 4 units” or “4.6.5
Image of splitting method when
synchronizing 2 units”.
0: Position1
Sets the rendering position to Position 1.
1: Position2
Sets the rendering position to Position 2.
2: Position3
Sets the rendering position to Position 3.
3: Position4
Sets the rendering position to Position 4.
Unit Count
Sets the number of VG to
synchronize.
Setting range: 1 to 4
* At present, only 1, 2, and 4 are enabled.
0: Slave1
Sets the unit to the 1st slave when Mode is set to Slave.
1: Slave2
Sets the unit to the 2nd slave when Mode is set to Slave.
2: Slave3
Sets the unit to the 3rd slave when Mode is set to Slave.
Time Out
Sets the timeout time of program
execution completion.
Specification range: 0 to 255
* Do not change the setting value from 0.
Reverse Mode
Reverses the rendering direction.
For details on output, refer to
“10.11.7 Scanning Direction
Image”.
0: No Reverse
This is the normal operation.
1: Left Right
Reverses the left/right direction.
3: Top Bottom
Reverses the top/bottom direction.
4: LR & TB
Reverses the top/bottom and left/right directions.
Slave Control Cnt
Sets the number of units for slave
control.
Setting range: 0 to 3
* At present, only 0, 1, and 3 are enabled.
* Set 1 when synchronizing two units.
* Set 3 when synchronizing four units.
Slave1 IP Address
Slave2 IP Address
Slave3 IP Address
Sets the IP address for slave
control. (XXX . XXX . XXX . XXX)
To Next Page
