Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
43
4.1.8 Output setting items
This section describes output settings for the HDMI unit.
Level 1
Level 2
Level 3
Setting item
Setting value
HDMI
Output
OFF/ON
[VG-876, 879]
Port1 to Port16
0: OFF / 1: ON
[VG-878,878-A] Port1 to Port4
HDMI or DVI
0: HDMI / 1: DVI / 2: Auto
Video Format:
0: RGB / 1: YCbCr4:4:4 /2: YCbCr4:2:2 / 3:YCbYr4:2:0
Width
0: Auto / 1: 8 bit / 2: 10 bit / 3: 12 bit / 4: 16 bit
Audio Output
0: OFF / 1: ON
Scramble
Only available for VM-1876-M6, VM-1876A-M6, VM-1876-M8,
VG-878, and VG-878-A.
*1 is only available for VM-1876-M8, VG-878, and VG-878-A.
The Scramble setting for configuration settings take priority for
this item.
0: ON (over 3.4G)
A Scramble processed HDMI signal is output when
TMDS clock 3.4G is exceeded.
1: OFF
HDMI signal is output without applying Scramble
processing.
2: ON *1
A Scramble processed HDMI signal is output
regardless of the TMDS clock.
3: Refer EDID *1
Checks EDID and determines whether or not to
apply Scramble processing.
InfoFrame/
Packet
Some
settings are
automatically
configured
according to
configuration
setting Auto
Select
settings.
Vendor
Specific
InfoFrame
OFF/ON
0: OFF / 1: ON
Type
1 (fixed)
Version
1 (fixed)
IEEE RegID Sel
0: Other / 1: H14b / 2: HF-VSIF
IEEE Regist. ID
According to IEEE RegID Sel
Other: 6 digits each 0 to F
H14b: 000C03 (fixed)
HF-VSIF: C45DD8 (fixed)
The following is only displayed when IEEE RegID Sel=Other is selected.
Payload Length
0 to 24
Payload 1-24
0x00 to 0xFF
The following is only displayed when IEEE RegID Sel=H14b is selected.
Video Format
0: None / 1: Ext. Resolution / 2: 3D
HDMI VIC,
* Only displayed when Video
Format=Ext. Resolution is
selected.
0: 4Kx2K 29.97/30Hz
1: 4Kx2K 25Hz
2: 4Kx2K 23.98/24Hz
3: 4Kx2K 24Hz(SMPTE)
3D Structure,
* Only displayed when Video
Format=3D is selected.
The output signal differs
from the standards. The DE
signal switches to HIGH for
the current Field alternative
Vblank3 interval.
0: Frame Packing
1: Field Alternative
2: Line Alternative
3: Side-by-Side (Full)
4: L + depth
5: L + d + G + G-d
( L + depth + graphics + graphics-depth )
6: Side-by-Side (Half)
7: Top & Bottom
1: Horizontal O/L, E/R
Horizontal sub-sampling
Odd/Left picture, Even/Right picture
2: Horizontal E/L, O/R
Horizontal sub-sampling
Even/Left picture, Odd/Right picture
3: Horizontal E/L, E/R
Horizontal sub-sampling
Even/Left picture, Even/Right picture
