Astrodesign VG-879 - SDI Output Setting Items

Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
90
4.3.4 SDI output setting items
Level 1
Level 2
Level 3
Setting item
Setting value
SDI
Output
OFF/ON
Port1 to Port16
Sets ON/OFF for each Port.
0: OFF / 1: ON
* The following cannot be set when other than Refer Program is selected for Mode in the SDI payload settings.
SDI Format
Sets the SDI format.
0: SD
1: HD
2: 3G-A
3: 3G-B
4: Dual HD
5: 6G * VM-1876-MB only
6: 12G * VM-1876-MB only
Video Format
Sets the color space of video output from SDI.
0: RGB
1: YCbCr4:4:4
2: YCbCr4:2:2:
3: YCbCr4:2:0 * VM-1876-MB
only
Width
Sets the output video bit length. This can be set to a bit length that is
independent of pattern rendering, or the same bit length can be selected
automatically.
* The portion of the bit length of pattern rendering that exceeds the bit length
set here will be truncated. Furthermore, if there is a missing portion, it will be
compensated for with “0.”
0: Auto
1: 10 bit
2: 12 bit
Split Count
Sets the number of screen splits.
* This is in accordance with the DotClk Mode setting in “2.1 ALL OUTPUT”.
0: No Split
1: 2Split(not use)
2: 4Split
Split Mode
Sets the split mode.
* This is in accordance with the Split Mode setting of the DotClk Mode setting
in “2.1 ALL OUTPUT”.
* Displayed only when 4Split
0: 4square
1: reserved1
2: reserved1
3. reserved1
4: reserved1
5: reserved1
6: reserved1
6: reserved1
7: reserved1
8: reserved1
9: reserved1
A: 2SI
Audio Output
Sets embedded audio output.
0: OFF / 1: ON
Audio Copy Ch2
Audio Copy Ch3
Audio Copy Ch4
Sets whether or not to copy the audio of the channel 2 and subsequent
channels of 3G SDI from Link 1.
0: No Copy
Superimposes the audio data
of only Link 1 (channel 1).
1: Copy Ch1
Copies the same audio data as
Link 1 (channel 1) to channels
2, 3, and 4.
