Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
59
● Specifications
DisplayPort
CH1
CH2
Standard
VESA DisplayPort Standard Ver1.2a
Connector
DisplayPort x2
Video
output
Dot clock
Single clock mode
(*1)
<For RGB/YCbCr444>
6 / 8 bit: 25 to 300 MHz
10 bit: 25 to 240 MHz
12 bit: 25 to 200 MHz
<For YCbCr422>
6 / 8 / 10 / 12 bit: 25 to 300 MHz
Dual clock mode
(*1)
<For RGB/YCbCr444>
6 / 8 bit: 50 to 600 MHz
10 bit: 50 to 480 MHz
12 bit: 50 to 400 MHz
<For YCbCr422>
6 / 8 / 10 / 12 bit: 50 to 600 MHz
Gradations
and
formats
RGB, YCbCr444
6 bit, 8 bit, 10 bit
YCbCr422
6 bit, 8 bit, 10 bit, 12 bit
Link rate
RBR : 1.62 Gbps
HBR : 2.7 Gbps
HBR2 : 5.4 Gbps
Audio
output
L-PCM
Number of channels
8CH (*2)
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96
kHz, 176.4 kHz, 192 kHz
Output frequency
20 to (1/2 of sampling frequency) Hz
Resolution
16 bit, 20 bit, 24 bit
Option
Next-generation audio compatible (*3)
DSD, Dolby Digital Plus, Dolby True HD
DTS HD (High Resolution Audio), DTS HD (Master Audio) etc.
AUX-CH
Transfer rate
1 Mbps
Support
functions
DPCD, E-EDID: Ver1.4, MCCS (DDC/CI): Ver1.1
External power supply
3.3 V / 500 mA with each channel
Copy protect
HDCP Ver1.3 Amendment for DisplayPort Revision 1.0
*1 For details, refer to “4.2.4 DisplayPort data transfer method”.
*2 When any of 3CH to 8CH output is ON, the number of channels will be output as 8CH.
*3 Not supported
