Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
37
● Specifications
HDMI
CH1
CH2
CH3
CH4
Connector
HDMI x2
Dot clock
*1
Single clock mode
<For RGB/YCbCr444>
8bit: 25 to 300 MHz
10bit: 25 to 240 MHz
12bit: 25 to 200 MHz
16bit: 25 to 150 MHz
<For YCbCr422>
8 / 10 / 12 bit: 25 to 300 MHz
Dual clock mode
*2
<For RGB/YCbCr444>
8bit: 597 MHz
<For YCbCr422>
12bit: 597 MHz
<For YCbCr420>
8bit: 50 to 600 MHz
10bit: 50 to 480 MHz
12bit: 50 to 400 MHz
16bit: 50 to 300 MHz
No. of colors
*3*4
RGB 8 / 10 / 12bit / 16bit each
(RGB / YCbCr444 / YCbCr422 / YCbCr420 compatible)
Audio
Output
HDMI
L-PCM
Sampling: 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192k
Output frequency: 100 to 20 kHz
No. of bits: 16 / 20 / 24bit
Copy protect
HDCP Ver2.2 or Ver1.4
Added functions
E-EDID Ver1.4 (DDC2B), xvYCC, CEC
*1 Quad clock mode is not supported.
*2 The same data is constantly output from CH1 and CH2 (distributed output). Distributed output is not supported.
*3 Up to 8-bit gradation is available for YCbCr4:2:0.
*4 Up to 12-bit gradation is available for 4K output.
