Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
92
Level 1
Level 2
Level 3
Setting item
Setting value
H Y-Sampling
Sets the H or Y sampling value.
0: 2
1: 1
Sampling Struc
Sets the sampling structure (video format).
0: 4:2:2(YCbCr)
1: 4:4:4(YCbCr)
2: 4:4:4(RGB)
3: 4:4:4:4(YCbCr+A)
4: 4:4:4:4(RGB+A)
5: 4:4:4(XYZ)
6: 4:2:0
7: 4:2:2:4(YCbCr+A)
8: 4:2:2:4(YCbCr+D)
9: 4:4:4:4(YCbCr+D)
A: 4:4:4:4(RGB+D)
Ch1 LinkA
Ch1 LinkB
Ch2 LingA
Ch2 LinkB
Ch3 LingA
Ch3 LinkB
Ch4 LingA
Ch4 LinkB
Sets the data stream.
0: Stream1(0h)
1: Stream2(2h)
2: Stream3(4h)
3: Stream4(6h)
4: Stream5(8h)
5: Stream6(Ah)
6: Stream7(Ch)
7: Stream8(Eh)
Audio Copy Ch1
Audio Copy Ch2
Audio Copy Ch3
Audio Copy Ch4
Sets whether or not to copy the audio of the Link 2 and subsequent
channels of 3G SDI from Link 1.
0: No Copy
Superimposes the audio data of only
Link 1 (channel 1).
1: Copy Link1
Copies the same audio data as Link 1
(channel 1) to channels 2, 3, and 4.
Dynamic Range
Set the dynamic range.
0: 100%
1: 200%
2: 400%
Bit Depth
Sets the bit length.
0: 8bit
1: 10 bit
2: 12 bit
The following are displayed when Mode = 2: Hex is set.
Byte 2
Sets byte 2.
00h to FFh
Byte 3
Sets byte 3.
00h to FFh
Byte 4 Ch1 LinkA
Sets byte 4 of Channel 1 Link A.
00h to FFh
Byte 4 Ch1 LinkB
Sets byte 4 of Channel 1 Link B.
00h to FFh
Byte 4 Ch2 LinkA
Sets byte 4 of Channel 2 Link A.
00h to FFh
Byte 4 Ch2 LinkB
Sets byte 4 of Channel 2 Link B.
00h to FFh
Byte 4 Ch3 LinkA
Sets byte 4 of Channel 3 Link A.
00h to FFh
Byte 4 Ch3 LinkB
Sets byte 4 of Channel 3 Link B.
00h to FFh
Byte 4 Ch4 LinkA
Sets byte 4 of Channel 4 Link A.
00h to FFh
Byte 4 Ch4 LinkB
Sets byte 4 of Channel 4 Link B.
00h to FFh
