Asus ESC4000A-E10 - Page 26

Chapter 2: Hardware Setup
2-6
6. Slide the external cap out of the rail
frame.
Rail frame
External cap
PnP cap
5. Slightly lift open the rail frame.
External cap
Load plate
Rail frame
4. Loosen each screw one by one in the
sequence shown on the socket to open
the load plate.
