Chapter 3: Installation Options
3-2
3.1 Friction Rail Kit
The rail kit package includes:
Friction rack rails
Fixing latches Set of screws
Latch screws
Rail Washers Rail screws
Rack railsFront end Rear end
3.1.1 Attaching the rack rails
Installing the tool-less rack rail
To install the tool-less rack rails into the rack:
1. Secure the two xing latches to the two sides of the server using the set of latch
screws.
The locations of the screw holes vary with different server models. Refer to your server user
manual for details.
