2-23
ASUS ESC4000A-E10
3. Once inserted, align and insert the M.2 card notch holes to the notches in the
expansion card cage, then slide the M.2 card to the front of the system so that the
screw holes on the M.2 card are aligned with the screw holes in the expansion card
cage.
4. Secure the M.2 card with two (2) screws as shown in the illustration below.
1
2
1
2
